Sargent Jump Test, Variations & How to Improve

February 09, 2025 6 min read

Sargent Jump Test, Variations & How to Improve

Who Invented the Sargent Jump Test & Why

The Sargent Jump Test, also known as the Vertical Jump Test, was created by Dr. Dudley Allen Sargent in 1921. Dr. Sargent was a pioneer in physical education and served as the Director of the Hemenway Gymnasium at Harvard University from 1879 to 1919. He developed this test as part of his work in assessing and improving physical fitness.
 He made significant contributions to the field of physical education and fitness assessment. In addition to creating the Sargent Jump Test, he invented various types of exercise equipment still used in gyms today and developed anthropometric charts for plotting physical development.

The Sargent Jump Test has become a widely used method for measuring lower limb explosive power and has influenced athletic performance evaluation for over a century. It remains a valuable tool in assessing vertical jump ability, particularly in sports like basketball and football.

Understanding the Sargent Jump Test

The Sargent Jump Test measures the vertical distance an individual can jump from a standing position. The test involves the following steps:

  1. The person stands side-on to a wall and reaches up with the hand closest to the wall.
  2. Keeping the feet flat on the ground, the point of the fingertips is marked or recorded. This is called the standing reach.
  3. The person then jumps vertically as high as possible using both arms and legs to assist in projecting the body upwards.
  4. At the highest point of the jump, the person touches or marks the wall.
  5. The difference between the standing reach height and the jump height is the score.

The best of three attempts is typically recorded as the final score, as you will see from the video below.

Video Showing the Sargent Jump Test

Sargent Jump Test Results Explained

The Sargent Jump Test results are typically expressed in centimeters or inches. Here's a general ranking scale for adult individuals based on the jump height:

Rating Men (inches) Men (cm) Women (inches) Women (cm)
Excellent > 28 > 70 > 24 > 60
Very good 24 - 28 61-70 20 - 24 51-60
Above average 20 - 24 51-60 16 - 20 41-50
Average 16 - 20 41-50 12 - 16 31-40
Below average 12 - 16 31-40 8 - 12 21-30
Poor 8 - 12 21-30 4 - 8 11-20
Very poor < 8 < 21 < 4 < 11

Muscles Used in the Sargent Jump

The Sargent Jump Test engages multiple muscle groups, primarily in the lower body:

  1. Quadriceps: These muscles at the front of the thighs are crucial for extending the knee and generating upward force.
  2. Hamstrings: Located at the back of the thighs, they work in coordination with the quadriceps and assist in hip extension.
  3. Gluteus Maximus: The largest muscle in the buttocks, it's essential for hip extension and power generation.
  4. Calves (Gastrocnemius and Soleus): These muscles provide the final push-off from the ground.
  5. Core muscles: Including the abdominals and lower back muscles, they stabilize the body during the jump.
  6. Hip Flexors: These muscles help in the initial crouching position before the jump.

While the lower body muscles are primary, upper body muscles such as the shoulders, arms, and chest also contribute to the overall jumping motion and height achieved.

It's important to note that these ranges can vary depending on the specific population being tested, such as elite athletes or different age groups.

Improving Sargent Jump Test Performance

To enhance performance in the Sargent Jump Test, athletes can focus on several key areas:

  1. Plyometric Training: Incorporate exercises like box jumps, depth jumps, and jump squats to improve explosive power.
  2. Strength Training: Focus on exercises that target the main muscle groups used in jumping, such as squats, deadlifts, and leg presses.
  3. Core Strengthening: A strong core helps in transferring power from the lower body through the upper body during the jump.
  4. Flexibility and Mobility: Improve the range of motion in the hips, knees, and ankles through stretching and mobility exercises.
  5. Technique Refinement: Practice the jumping technique, focusing on arm swing coordination and proper landing mechanics.
  6. Power-to-Weight Ratio: Optimize body composition by reducing excess body fat while maintaining or increasing muscle mass.
  7. Rest and Recovery: Ensure adequate rest between training sessions to allow for muscle recovery and adaptation.
  8. Nutrition: Maintain a balanced diet that supports muscle growth and recovery.
  9. Warm-up Properly: A study showed that specific warm-ups using half-squats at low and moderate intensity can positively affect vertical jump performance.





Equipment Needed for the Sargent Jump Test

The Sargent Jump Test can be conducted with minimal equipment, making it accessible for various settings as our video shows. However here are some more  common tools used dependant on your budget and accuracy of data capture:

  1. Wall and Measuring Tape: The original method uses a wall and a measuring tape to mark and measure the jump height.
  2. Chalk: Used to mark the wall at the standing reach and jump height points.
  3. Vertec: A specialized apparatus with horizontal vanes that rotate when touched, providing a clear visual of the jump height.
  4. Jump Mat: A rubber mat with sensors connected to a handheld computer that calculates jump height based on flight time.
  5. Force Plate: A more advanced option that measures ground reaction forces to determine jump height.
  6. Photoelectric Circuits: Systems using laser or infrared beams to measure jump height.
  7. Accelerometer-based Devices: Wearable technology that uses accelerometry to measure jump height.
  8. Video Equipment: High-speed cameras can be used to analyze jump technique and measure height when combined with calibration tools.

Sargent Jump Test Advantages and Disadvantages

Advantages:

  1. Simple and quick to perform
  2. Provides a direct measurement of vertical power
  3. Minimal equipment required for basic testing
  4. Widely used, allowing for comparison across different populations
  5. Can be used to track progress over time

Disadvantages:

  1. Technique plays a significant role in maximizing scores
  2. Potential for cheating by manipulating the standing reach measurement
  3. May not be suitable for individuals with certain injuries or conditions
  4. Does not provide detailed information about muscle activation or force production
  5. Results can be affected by factors such as arm swing and counter movement

Sargent Jump Test Variations and Applications

The Sargent Jump Test has several variations that can be used depending on the specific goals of the assessment:

  1. Squat Jump: Performed from a static squatting position to isolate leg power without the counter movement.
  2. Counter movement Jump: The standard version with a preparatory downward movement.
  3. Arm-Restricted Jump: Performed with hands on hips to focus solely on lower body power.
  4. Single-Leg Jump: Assesses unilateral leg power and can help identify imbalances.
  5. Approach Jump: Includes a running start, which is more sport-specific for activities like volleyball or basketball.

These variations allow coaches and PT's to isolate specific aspects of jumping performance and tailor the test to sport-specific needs.

Sargent Jump Test Validity and Reliability

The Sargent Jump Test has been widely studied for its validity and reliability. Research has shown that it is a valid measure of lower limb explosive power, particularly in sports that involve jumping. A study on a group of footballers  found that the Sargent Jump Test is as valid as a field test in assessing explosive strength.However, it's important to note that the reliability of the test can be affected by factors such as the tester's experience, the athlete's familiarity with the test, and the specific protocol used. Consistency in test administration is crucial for obtaining reliable results over time.

Concluding Thoughts

The Sargent Jump Test remains a valuable tool in assessing lower limb power and explosive strength. Its simplicity, minimal equipment requirements, and widespread use make it an attractive option for coaches, athletes, and researchers. While it has some limitations, such as the influence of technique on results, it provides a quick and effective means of evaluating vertical jump performance.As technology advances, new methods for measuring vertical jump height are emerging, offering greater precision and additional data points. However, the fundamental principles of the Sargent Jump Test continue to be relevant in athletic assessment and performance monitoring.

By understanding the muscles involved, the proper technique, and methods for improvement, athletes can use the Sargent Jump Test as a benchmark for their explosive power development. Combined with a comprehensive training program that includes plyometrics, strength training, and technique refinement, individuals can work towards enhancing their vertical jump performance and overall athletic capabilities.
